Bearing Grab Screw Type
SKU:AS205
Technical Specifications:
Type: Insert Bearing
Bore Type: Round
Bearing Type: Ball Bearing
Material: Through Hardened Steel
Limiting Speed - Grease: 5900 RPM
Seal Type: Contact
Seal Material: Nitrile Rubber
Precision Rating: ISO Class 0
Performance: Standard Duty
Locking Device: Set Screw
Lubrication: Non-Relubricatable
Basic Outer Ring: 205
Static Load Rating:
1760 lbf
7850 N
7.85 kN
Dynamic Load Rating:
3150 lbf
14000 N
14.00 kN
Enclosure: Double Sealed
Weight:
0.348 lb
0.158 kg
Operating Temperature Range:
-40 to 250 degF
-40 to 120 degC
Type: Insert Bearing
Bore Type: Round
Bearing Type: Ball Bearing
Material: Through Hardened Steel
Limiting Speed - Grease: 5900 RPM
Seal Type: Contact
Seal Material: Nitrile Rubber
Precision Rating: ISO Class 0
Performance: Standard Duty
Locking Device: Set Screw
Lubrication: Non-Relubricatable
Basic Outer Ring: 205
Static Load Rating:
1760 lbf
7850 N
7.85 kN
Dynamic Load Rating:
3150 lbf
14000 N
14.00 kN
Enclosure: Double Sealed
Weight:
0.348 lb
0.158 kg
Operating Temperature Range:
-40 to 250 degF
-40 to 120 degC
(AS205)
SKU | AS205 |
Barcode # | 9310754826773 |
Brand | CBC |
Shipping Weight | 0.6000kg |
Shipping Width | 100.000m |
Shipping Height | 100.000m |
Shipping Length | 100.000m |
