CT5 Series LED Signal Tower 24VDC, Steady LED: Red/Amber/Green, Buzzer Module, 100mm Tube Mounting

MODUL-COMPETE 50 MODULAR SIGNAL TOWER dia 50MM
Cost-optimised modular 50 mm dia signal tower for classic 24V DC and IO-Link applications in industry
Up to 5 positions possible
Low soiling due to flat-flush smooth exterior design
Maximum product availability due to minimum number of articles (only 23 order numbers)
LED multifunction and LED continuous light modules in 6 colours
Efficient sound module selectable up to 95 dB - 8 tones
Optimised ‘resilient’ bayonet system enables high stability, even without sealing rings five-pole M12 base with automatic contacting push-in system
All common mounting types
Technical Data:
Housing dia 50 mm, black (RAL 9005)
Lens Polycarbonate, ribbed inside
Type of mounting horizontal, vertical, Tube mounting or NPT 1/2inch
Beacon type:
LED steady light, flashing light,
strobe light and double strobe light
Light source: LEDs
Tone: see tone table
Volume: 95 dB
Duty cycle: 100 %
Service life Light source: 100.000 h
Number of possible modules max. 5
Operating temperature: 30 degC / +60 degC
Operating temperature: -30 degC / +60degC
Degree of protection: IP65 & UL Type 4/4x/13
Impact resistance: IK07
Weight (modules): 26-149 g
