Amber Led Indicator Lamp 12/24V T/S J3Barrm / J3Barwm

Jumbo Series LED Rear Direction Indicator Lamp 12/24 Volt
Can be used as a replacement lamp in the J2 / J3 Series Combination Lamp Housing Assembly
Amber Illumination
24 x High Intensity White LED's
Faceted Reflectors with Amber Hardened Acrylic pattern free Lens and Reflex Reflector
Black ABS Plastic Housing with mounting screws and caps included
Surface Mount- low mounting depth for easy installation
Pre-wired 100mm Lead
Fully encapsulated circuitry
Sealed against Dust and Moisture
0.42amps at 12 Volt and 0.28amps at 24 Volt Current Draw
ADR 6/00 2A Rear Indicator Lamp specifications approved- CRN 42964
ADR 47/00 Reflector specifications approved- CRN 42966
Refer to ADR 13/00 for mounting instructions
Bulk Pack Qty: 1v5 Year Warranty
Spare Parts:
J3B3B Black Triple Bracket
Specifications:
Colour: Amber
Type: LED
Shape: Rectangular
Voltage: 12/24V
Mount: Surface
Width (mm): 190
Height (mm): 122
Depth (mm): 30
