Redarc DC-DC In-Vehicle Battery Charger With 12/24V Input 20A Output

Description:
The BCDC1220 is a multi stage, 12V, 20A, DC-DC battery charger that operates from an input of either 12V or 24V nominal. The input voltage of the BCDC1220 can be above, below or equal to the output voltage making it ideal for charging an auxiliary 12V battery where the distance from the main battery may cause a significant voltage drop.
Features:
On board Multi stage charging regardless of their type and size
Selectable Multi-stage smart charging profiles for optimal charging of all automotive battery types
Over current, short circuit, and reverse polarity protected
High operating temperature range up to 80 degC with over temperature protection
Input under and over voltage shutdown
Easy LED indication of selected battery type and charging stage
Fully sealed in silicon elastomer - Suitable for marine or dusty environments
Contains step up & step down circuitry, designed to give the best charge to your auxiliary battery
Specifications:
Rec. battery Types: GEL AGM, Calcium Content
Float Voltage - All: 13.3V
Instructions Included: Yes
Max. Voltage Calcium: 15.3V
Max. Voltage GEL AGM: 14.5V
Orange Wire: Profile Select
Amperage - Standby: <8mA
Amperage - No Load: <100mA
Height: 37mm
Operating Temp: -20C to +80C
Max. Voltage Std Lead Acid: 14.9V
Width: 120mm
Length: 100mm
Height (mm): 37
Weight: 450g
Length (mm): 100
Brand: Redarc
Warranty: 2 Years
Width (mm): 120
Input Voltage: 12/24V
Voltage - Input: 12/24V
Recommended Fuse: 30A Input, 25A Output
Amperage: 20A
Approvals: EMC: C-Tick, AS/NZS CISPR11:2004
Operating Temperature: -20C to +80C
Red Wire: Input Positive
Blue wire: Input Trigger
Black Wire: Common Ground
Wattage: 300
Brown Wire: Output Positive
