TOGGLE SWITCH ON/OFF PRE-WIRED W/6" LEAD WEATHERPROOF 12V 6a
SKU:SW5042BL
RRP $65.18
$41.47
SAVE $23.71 (36%)
Not Available In Store
Calculate Shipping
Specifications:
Voltage: 12 - 24 VOLT
Amps: 6
Function: ON / OFF
Number of Terminals: 2
Number of Postions: 2
Contact Configuration: SPST
Contacts: NO
Jaylec Marine Toggle Switch On/Off 12/24 Volt 6amp.
2 Position - On/Off- Single Pole - Single Throw- Chrome plated Toggle with Neoprene Rubber Boot.
Maximum Load: 6amp at 12 Volt- 3amp at 24 Volt.
Silver Contacts.
Neoprene covered housing- pre-wired with 2 x 6.35mm leads- 6.7" or 170mm long.-11.90mm Mounting Stem diameter with a 15/32"-32 Thread and 7.50mm long.
Suits panel thickness up to 4.76mm.
Toggle Handle length: 11mm.
Weather proof- protected against moisture and dust.
64mm x 26mm x 17mm.
Jaylec
1 year Warranty.
Voltage: 12 - 24 VOLT
Amps: 6
Function: ON / OFF
Number of Terminals: 2
Number of Postions: 2
Contact Configuration: SPST
Contacts: NO
Jaylec Marine Toggle Switch On/Off 12/24 Volt 6amp.
2 Position - On/Off- Single Pole - Single Throw- Chrome plated Toggle with Neoprene Rubber Boot.
Maximum Load: 6amp at 12 Volt- 3amp at 24 Volt.
Silver Contacts.
Neoprene covered housing- pre-wired with 2 x 6.35mm leads- 6.7" or 170mm long.-11.90mm Mounting Stem diameter with a 15/32"-32 Thread and 7.50mm long.
Suits panel thickness up to 4.76mm.
Toggle Handle length: 11mm.
Weather proof- protected against moisture and dust.
64mm x 26mm x 17mm.
Jaylec
1 year Warranty.
(SW5042BL)
| SKU | SW5042BL |
| Barcode # | 9310754869541 |
| Brand | Jaylec |
| Shipping Weight | 0.3000kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.150m |
